Li po 3.7V 1500mAh

Name: Li po 3.7V 1500mAh
Brand: SmartBatteryStore
Price: 260.0 INR
Availability: InStock
Rating: 5.0 (10 reviews)

Want it delivered by

Available:

Only 0 item in stock

0 item in stock

In stock

Pre-order

Out of stock

Rs. 260.00

Description
Specifications
Reviews

UFX 803450- 3.7V 1500mAh Rechargeable Li Po Battery. This Standard UFX 803450 3.7 V Rechargeable 1500mAh Li Po Battery Cell is a single tiny cell with a 1500mAh capacity. This Li Po Battery battery is very convenient to install in your project where higher current needed with space constraint. UFX 803450 - 3.7V 1500mAh Rechargeable Li Po Battery is a source of power for various portable devices including flashlights, hobby transmitters, and receivers, etc.

Mode No.	UFX 803450
Electrical Characteristics
Rated Capacity	1500mAh
Nominal Voltage	3.7 V
Resistance/Initial Impedance	≤ 180mΩ
Cycle Life	>300 times
Self Discharge Rate
Charging & Discharge Characteristic
Standard Charge Current	300mA (0.2C)
Max Continuos Charge Current	1500mA (1C)
Standard Discharge Current	300mA (0.2C)
Max Continuos Discharge Current	1500mA (1C)
PCM Specification
Over-charge Protection Voltage	4.2 V
Over-discharge Protection Voltage	2.4 V
Over-current Protection for Discharge	3A
Short Circuit Protection	YES
Mechanical Characteristic
Typical Weight	≈ 27g
Dimensions	(T)8.2(w)34.3(H)53mm
Wire	100± 3 mm
Connector	JST PHR-2
Temperature Characteristic
Discharge Temperature	-20 ～ 60℃
Charge Temperature	0～ 45℃
Recommend Storage Temperature	15℃～35℃， 85% RH Max.
